Most of the foam in mine has crumbled off and rests in the bottom of the box. Some of these doors were supposed to be covered with a thin layer of foam. There are many doors inside the box which control where the air comes out. This weekend I will be cleaning and repairing the broken fiberglass. I've opened the box up and discovered that at some point the heater core was replaced and during the replacement process some of the fiberglass was damaged. I removed the dash and the whole box out of the car. I'm in the process of doing exactly the same thing. There's an expansion valve, electro/vacuum compressor switch, vacuum motors and a half mile of vacuum hose to replace (after 50 years, assume it's leaking somewhere-it will).Įither way you go, start by getting the books mentioned above. The core is not the only thing that should be inspected. Joking aside, you should really consider the dashboard-out method. But, if you like taking puzzles apart and putting them back together again, this will be a lot of "fun", per JIm. Removing the dashboard is a significant project by itself. An alternative is to remove the dashboard entirely, and the guts become much more easily accessed. It strikes me as a good way to go insane, if it's not in fact impossible.
66 thunderbird distribution valve manual#
The manual outlines a detailed procedure for removing the plenum with the dash in place. As stated, the evap core is located inside the A/C plenum. Tbird wrote:Welcome to the forum you will find a lot of assistance when need in this group.
66 thunderbird distribution valve plus#
Most of these items should be available from your favorite Thunderbird supply house orĭirectly from Jim Osborn Reproduction, cost will be about 125.00 plus shipping cost These must be for your year of vehicle as there were many changes made from one VTCI Original Factory Specifications (VTCI Country Store, available to members only) Wiring Diagram Manual (Jim Osborn Reproductions)
Thunderbird Shop Manual (used or Jim Osborn Reproductions)īody Trim and Sealant Assembly Manual (Jim Osborn Reproductions)Įlectrical Assembly Manual (Jim Osborn Reproductions) Owners Manual (used or Jim Osborne Reproductions) Would suggest that you obtain the following printed information to help with any work that you are going to undertake these cars are very complex for their time and not easy to locate all the relays and wiring in them. The evaporator core is installed inside the heater box under the dash it will be fun to get at with the dash in place. Welcome to the forum you will find a lot of assistance when need in this group.
